Heavy Duty Bollard-Round

​Model #: HDBR

LED Lumen Output: 1669 lumens

LED Lumens / Watt: 48

LED Input Watts: 35

CCT: 27K, 3K, 4K, 5K

CRI: 80+ Standard (90+ Optional)

Type V Round Distribution

Dimension (inches): 8” Round x 42” Tall

Bollard Specification

Bollards combine architectural design and contemporary styling. Suitable for walkways and commercial areas where low mounting fixtures are required.

Available in 35 to 100watt medium base high pressure sodium lamp, or 50 to100 watt medium base metal halide lamp. Also available with 26PL-42PL compact fluorescent lamp or LED. Luminaire shall be completely pre-wired for ease of installation.

Basic Product Description

One-piece extruded aluminum 8” diameter (round) or 6-3/4” (square) secured to a cast aluminum mounting base with four tamper resistant screws. Installation by using four 9” inch anchor bolts, leveling nuts and washers.

The Bollard is finished in all weather bronze polyester powder coating (other finishes are available). A 1/4” thick acrylic diffuser is sealed to the post with a full EDPM gasket, sealing out moisture and dust. Easy component and lamp access is provided by removing tamper resistant screws on top of the cap. All ballast components are mounted within easy reach.
